Ubiquiti UniFi U7 Pro Outdoor - Wi-Fi 7 AP, 2.4/5GHz, up to 9.3 Gbps, sector, 1x 2.5GbE, outdoor, PoE+ (without PoE injector)

Ubiquiti UniFi U7 Pro Outdoor

The Ubiquiti UniFi U7 Pro Outdoor is an outdoor Wi-Fi 7 AP supporting both 2.4 and 5 GHz frequency bands and delivering speeds of up to 8.6 Gbps for 5 GHz and 688 Mbps for 2.4 GHz . Designed specifically for professional and enterprise deployments, the U7 Pro is ideal for applications requiring flawless Wi-Fi services in demanding, large-scale environments. It supports PoE+ power.

The UniFi U7 Pro Outdoor is a reliable outdoor hotspot solution using the 802.11a/b/g/n/ac/ax/be standard. It is equipped with a MIMO 2×2 and MIMO 4×4 antenna system in the form of integrated directional antennas with a gain of 8 dBi/11 dBi (2.4 GHz/5 GHz) and a beamwidth of 90°/90° (2.4 GHz/5 GHz) . The package also includes two external omnidirectional antennas with a gain of 6 dBi/8 dBi (2.4 GHz/5 GHz), which also support software beamwidth adjustment.

•

• Wi-Fi 7

• 6 data streams

• Coverage 465 m ²

• Software switching from internal directional antennas to external omnidirectional antennas (included)

• WPA3 encryption

• More than 300 connected devices

• Power supply via PoE+ (802.3at)

• Wall or pole mounting (⌀ 25–63.5 mm)

• Weather resistance (IPX6)

• Operating temperature -30 to +60 °C

• 2.5GbE uplink


Management via UniFi Network App : version 9.0.108 and later

UniFi devices can be configured and managed using the UniFi Network application, which is pre-installed on UniFi OS consoles (UniFi Dream Machine, Dream Router, Dream Wall, Express, Cloud Gateway Ultra, etc.). Alternatively, the freely available UniFi Network Server software is available for installation on your own computer or server (Windows, MacOS, Linux). The UniFi Network Server software is constantly being improved, so we recommend always using the latest version, which you can download from the Ubiquiti website in the Download section. You can also learn more about this product at the Ubiquiti training .

BASIC SPECIFICATIONS

Standard: 802.11a/b/g/n/ac/ax/be

Antenna: integrated directional antenna 8 dBi (2.4 GHz) + 11 dBi (5 GHz), 2× RP-SMA connector (2× external omnidirectional antenna included)

Operating frequency: 2.4 GHz, 5 GHz

Data transfer rate: 688 Mbps (2.4 GHz), 8.6 Gbps (5 GHz)

PoE: yes, active PoE+ 802.3at

Ports : 1× 2.5GbE RJ-45

Dimensions: 208 × 170 × 121.8 mm (208 × 170 × 66.5 mm without holder)

Weight: 1.2 kg (1.33 kg with holder)

Manual (assembly instructions):

Ubiquiti UniFi U7 Pro Outdoor
