Tinycontrol SCD40
CO2, temperature and humidity sensor based on the principle of photoacoustic sensing. The sensor board is equipped with an I2C interface.
CO2 measurement range (0-40,000 ppm)
Measurement accuracy: 400–2000 ppm ±(50 ppm + 5% of reading)
Repeatability: ±10 ppm
Reaction time: 60 s
Humidity measurement range (0-100% RH)
Accuracy (typ. +15 to +35 °C, 20 ÷ 65 %RH): ±6 %RH
Accuracy (-10 to +60 °C, 0 to 100% RH): ±9% RH
Repeatability: ±0.4% RH
Reaction time: 90 s
Temperature measurement range (-10 to +60 °C)
Accuracy (typ. +15 to +35 °C): ±0.8 °C
Accuracy (-10 to +60 °C): ±1.5 °C
Repeatability: ±0.1 °C
Reaction time: 120 s
BASIC SPECIFICATIONS
Supply voltage: DC 2.4–5.5 V (typically 3.3/5 V)
Max. peak current consumption: 175 mA
Max. wire length for I2C: 0.5 m
Dimensions: 59 × 27 mm
Data sheet
