Launch a supported video conferencing app—like Zoom®, Microsoft Teams®, and more—directly on your device without the need for a computer or laptop.
Ensure a neat and tidy installation with reliable cable management and minimal cable routing. Use a variety of mounting options to quickly and easily install the Rally Bar Mini across all your small rooms.
REALISTIC APPEARANCE
Enhance your conferences with high-quality images, excellent colors, and full room coverage.
STAY FOCUSED
Using artificial intelligence, human perception, and motorized pan and tilt, Rally Bar Mini adapts to the dynamics of the conference and focuses the camera on what's happening in the room.
AMAZING SOUND
The Rally Bar Mini's advanced sound technology delivers rich, natural sound, ensuring every voice is clearly understood.
STAY FOCUSED
Using artificial intelligence, human perception, and motorized pan and tilt, Rally Bar Mini adapts to the dynamics of the conference and focuses the camera on what's happening in the room.
AMAZING SOUND
The Rally Bar Mini's advanced sound technology delivers rich, natural sound, ensuring every voice is clearly understood.
Automatically balances loud and soft voices – while suppressing unwanted noise – with AI-powered RightSound technology that improves over time. Focuses on the active speaker with high-precision beamforming microphones.
You will hear and be heard at the same time thanks to excellent, full-duplex communication.
EXPAND THE CONVERSATION
Easily meet the demands of any small room or space, starting with a 4.6m microphone pickup range (varies depending on environment) with the option to add up to 2 Rally table microphones.
SUPER SMART
Keep the camera focused on conference participants with the intelligent viewfinder, which uses the frame overview feature to optimize automatic aiming and control of the RightSight™ camera.
AI-DRIVEN OVERVIEWS
Track room usage data from the Logitech Sync Dashboard, captured by the Smart Viewfinder's people counting feature.
Simple administration
Monitor and manage conference room devices from a single platform with Logitech Sync. Plus, get corporate visibility into your room usage.
Technical parameters
Certification and compatibility
Certifications: Zoom Certified, Certified for Microsoft Teams as a USB device. Please contact the manufacturer for more information on submitted and awarded certificates.
Compatibility: USB plug-and-play connection with virtually any video conferencing application
Device Mode: Supports compatible video conferencing software in device mode (no PC required), including Zoom Rooms
Certificate requests submitted for Microsoft Teams Rooms on Android and other video conferencing platforms.
GENERAL PARAMETERS
Integrated components: 6 beamforming microphones, PTZ camera, 3 speakers, smart viewfinder, cable management system, desk stand, Logitech CollabOS platform
Case: Universal case with integrated table stand and patented speaker damping system eliminates camera shake caused by vibrations and audio interference
Device Management: Logitech Sync
Supported displays: 2
Display resolution: 1080p
Network protocol supportrounds: IPv4, IPv6
Proxy Support: IP-based proxy, FQDN-based proxy, PAC file proxy
Camera
Resolution: 4K, 1440p, 1080p, 900p, 720p and SD at 30 fps
Panning: Motorized ±25°
Tilt: Motorized ±15°
Zoom: 4x HD digital zoom
Diagonal viewing angle: 120°
Horizontal viewing angle: 113°
Vertical viewing angle: 80.7°
Total room coverage (field of view + pan and tilt): 163 horizontal x 110 vertical
Woofer
Transducer: 70 mm
Sensitivity: 92 dB SPL at 1 W, 99 dB SPL at 8.0 W, always with +/- 2 dB at 1 meter
Rated power: 8W
THD: 1 kHz < 2% at 1 W
Speaker sampling frequency: 48 kHz
Impedance: 4 Ohms
Center speakers
Drivers: 2x 43 mm
Sensitivity: 84 dB SPL @ 1 W / 1 m
Rated power: 4W
THD: 1 kHz < 2% at 1 W
Speaker sampling frequency: 48 kHz
Impedance: 4 Ohms
Microphones
Frequency response: 90 Hz–16 kHz
Sensitivity: >-36 dB FS +/-1 dB at 1 Pa
Microphone data rate output: 48 kHz
Sensing range: 4.5 m
Beamforming elements: Six omnidirectional microphones (digital MEMS) forming five adaptive side acoustic beams
Audio processing: AEC (Acoustic Echo Cancellation), VAD (Voice Activity Detector)
Noise reduction: Artificial intelligence-based noise reduction algorithm
Additional microphones: Supports up to 2 additional Rally desktop microphones
RightSense™ Technology
RightLight: Renders the natural skin tones of each participant
RightSight: Maintains a constant overview of the room and detects human figures for automatic participant capture
RightSound: Distinguishes speech from other sounds to automatically balance voices, suppresses background noise and echo
Interface
HDMI Out: 2
HDMI In: 1
USB: 3x type A, 1x type C
Network: 10/100/1G Ethernet network
WiFi: 802.11 a/b/g/n/ac
External microphone input: Yes (proprietary input supports optional Rally desk microphone, Rally desk microphone splitter, and Rally desk microphone extension cable)
Remote control: Bluetooth® Low Energy
Power and cables
Power source: Auto detect
Operating voltage/power supply: 100-240V, 19V, 4.74A
Power supply dimensions: 127 mm × 51 mm × 30 mm
DC cable: 1.5m
AC cable: 1m
HDMI 1.4 cable: 2m
USB A to USB C 3.0 cable: 2.2 m
Environment
Operating temperature: 0 to 40°C
Storage temperature: -40 to 70°C
Humidity: 10 to 95%
W: 16.7 idle, 18.7 conference
Security
Full disk encryption: AES-128
Data Security: Symmetric Keys, PKI
Device Identity: Protected by device certificate
Device Access: API Authentication
Key protection: Arm TrustZone, RPMP
Package contents
Rally Bar Mini
Power source
AC power cord
HDMI cable
USB cable
Remote control Main lens and Intelligent viewfinder caps
User documentation
Size x:78 cm
Dimensions: 19 cm
Size: 19 cm
Weight:5.803 kg
