| Expansion Slots |
| PCIe |
- 1 PCIe 5.0 x16,
- 2 PCIe 4.0 x4 (in x8 slot)
|
| M.2 |
- M.2 Interface: 1 PCIe 4.0 x4
- Form Factor: 2280/22110
- Key: M-Key
|
| System BIOS |
| BIOS Type |
|
| BIOS Features |
- ACPI 6.1
- SMBIOS 3.0 or later
- PCI FW 3.0
- UEFI 2.7
- RTC (Real Time Clock) Wakeup
|
| Management |
| Software |
- SuperDoctor® 5, SUM, AMT, vPro, IPMI (Intelligent Platform Management Interface) v2.0 with KVM support, IPMICFG, IPMIView for Linux/Windows, SMCIPMITool
|
| System Management Software |
- Wake-on-LAN, Watchdog, KVM with dedicated LAN
|
| Power Configurations |
- ACPI Power Management, ATX Power connector, +12V DC Power Input
|
| PC Health Monitoring |
| Voltage |
- VBAT, Memory temperature, CPU temperature, Chipset Voltage, 4 fans with tachometer monitoring, 1.05 (PCH), +5V standby, +5V, +3.3V, +12V, +1.8V, +1.5V, +1.35V, 5 fans with tachometer status monitoring, BMC/IPMI Heartbeat LED, Dual Cooling Zone, UID
|
| LED |
|
| Temperature |
- Monitoring for CPU and chassis environment
- CPU thermal trip support
|
| Other Features |
- RoHS, M.2 NGFF connector, Chassis intrusion detection, ATX Power connector, ACPI power management, 12V DC or ATX Power Source
|
| FAN |
- 5x 4-pin fan headers (up to 5 fans)
|
| Operating Environment |
| Operating Temperature Range |
- 0°C - 60°C (32°F - 140°F)
|
| Non-Operating Temperature Range |
- -40°C - 85°C (-40°F - 185°F)
|
| Operating Relative Humidity Range |
- 10% - 85% (non-condensing)
|
| Non Operating Relative Humidity Range |
- 5% - 95% (non-condensing)
|
|
