XtendLan Outdoor rack for 19", 11U, depth 300mm, IP55, gray

XtendLan WEH-11U-503060

Waterproof cabinet, IP55 protection, mounting frame for 19" devices. Three-layer surface treatment (phosphating, dipping in primer, powder coating), solid construction. Removable cable entry cover.

It is made of rolled steel, the supporting parts are made of 1.5 mm thick steel.

Door opens 110 degrees, right or left mounting (user-interchangeable opening).

Vertical mounting rails for 19" devices - left and right

Accessories include mounting screws, 1x universal wrench.

Mounting holes for wall mounting: always 20mm from the outer edges. Included are ears for mounting above and below the cabinet with an overlap of 10mm on each side. Offset from the wall when using them +8mm.

BASIC SPECIFICATIONS

Rack format: 19"

Capacity: 11U

Protection level: IP55

Dimensions: 500 x 300 x 600 mm (width x depth x height)

Color: gray, RAL7032

Standards: IEC60529, EN60529/10.91, GB4208-93

Fixed hinges and door grounding:

Lock detail:

Accessories:
