XtendLan MTB-LA40W2733
SFP+ module for 10Gbit Ethernet. LC simplex connector. Single fiber, WDM. Reach 40km on singlemode fiber.
Transmitting wavelength 1270 nm, receiving 1330 nm. Power margin at least 16 dB. DDMI. Multirate Fiber channel. Support for most manufacturers (Cisco, Dell, Planet, ...)
Conversion Gigabit module miniGBIC Small-Form-Pluggable (SFP). Standard 1000Base-LX, IEEE82.3z. Duplex LC connector, for single-mode fibers.
CWDM modules allow multiple wavelengths to be transmitted over an optical fiber (or one pair of fibers). Each module operates at a different wavelength with a spacing of 20nm. Optical signal combining and splitting is performed on a passive optical splitter/combiner.
Conversion 10Gigabit module in the Small-Form-Pluggable (SFP) format. Standard 1000Base-LR/LW, IEEE802.3ae, 10.3125Gbit/s. Simplex LC connector, for singlemode fibers. Expands/converts ports of switches and converters with a slot for SFP+.
For connection between WDM modules, it is necessary to combine the TX/RX wavelengths of the counterpart sides, pairs of modules are distinguished by a code representing side A or B.
BASIC SPECIFICATIONS
Module type: SFP+
Connector: LC simplex
Wavelength (transmission/reception): 1270 nm / 1330 nm
Fiber type: Singlemode
Connection range: up to 40 km
Transmission margin: 28 dB
Sensitivity: -15 dBm
Transfer rate: 10.3 Gbps
