IMMAX NEO SMART ultrasonic liquid level sensor, IP65, range 5m, Wi-Fi, TUYA

Intelligent ultrasonic sensor for precise liquid level monitoring with a range of up to 5 meters.

The Immax NEO Smart liquid level sensor uses advanced ultrasonic technology for non-contact measurement with an accuracy of ±0.02 m . Thanks to the 2.4 GHz WiFi connection, you can monitor the liquid level remotely via the Immax NEO PRO application in Czech and 60 other languages.

The device is suitable for any type of liquid and, thanks to the IP65 protection rating, it works reliably even outdoors at temperatures from -20°C to +70°C. The possibility of connecting to smart water valves allows automatic refilling when the tank is empty and switching off when the maximum is reached.

Advanced automation and notifications
The sensor allows you to set your own level limits and automatically notify you when they are exceeded. By integrating with smart valves, you can create a complete automatic system for maintaining optimal levels in tanks.

Easy installation and power supply
The device is powered by the supplied AC 220V-230V/50-60Hz adapter with DC 5V 1A output. The maximum installation height is 5 meters, the operating current does not exceed 55 mA.

Package contents
The package includes a sensor, power adapter, installation materials and a user manual in Czech for quick setup.

BASIC SPECIFICATIONS

Detection technology: ultrasonic

Detection range: 0.1 – 5 m

Accuracy: ±0.02 m

Communication: WiFi 2.4 GHz IEEE 802.11b/g/n

RF output power: 20 dBm

WirelessOperating range: 30 m line of sight, 5 m in built-up areas

Power supply: DC 5V 1A (AC adapter 220V-230V/50-60Hz)

Working current: > 55 mA

Operating temperature: -20°C to +70°C

Operating humidity: 0 to 100% RH

Protection level: IP65

Dimensions: 80 × 80 × 41 mm

Weight: 310g
