Grandstream GWN7664ELR Outdoor Wi-Fi 6 Access Point

Grandstream GWN7664ELR

Outdoor Wi-Fi 6 access point designed for high-density enterprise wireless networks. Eight internal high-gain antennas with OFDMA technology support provide a strong and reliable Wi-Fi signal for up to 512 connected wireless devices . For easy installation and management, it supports GWN.Cloud - Grandstream's free cloud platform. The GWN7664ELR is the ideal Wi-Fi access point for deploying Voice-over-Wi-Fi solutions and offers seamless connectivity to Grandstream voice and video IP phones. With support for QoS, low-latency applications, Mesh networks and captive portals, it is the ideal outdoor access point for enterprises, multi-story offices, warehouses, hospitals, schools and more.

•

• Aggregated speed 6 Gbps (wireless throughput), 1× 2.5Gigabit SFP port and 1× 2.5Gigabit RJ-45 port

• Dual-band 4×4:4 MIMO technology with OFDMA support

• Coverage up to 300 meters

• Support for up to 512 Wi-Fi client devices

• Advanced QoS to ensure real-time, low-latency application performance

• Anti-hacking secure boot, critical data/control + digital signature locking, certificate security, random default password for each device

• Power adaptation and automatic PoE/PoE+ detection

• The built-in controller can manage up to 50 local APs (GWN series). GWN.Cloud - unlimited AP management, GWN Manager - software controller


BASIC SPECIFICATIONS

Standard: IEEE 802.11a/b/g/n/ac/ax

Data transfer rate: 5 GHz - 4804 Mbit/s, 2.4 GHz - 1147 Mbit/s

Antenna: 8× 1-band internal antenna (5.5 dBi for 2.4 GHz, 6.5 dBi for 5 GHz)

Ports: 1× 2.5G SFP, 1× 2.5GbE RJ-45

Frequency: 2.4GHz, 5GHz

Security: WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES), WPA3, anti-hacking boot, digital signature/certificate management, random default password

PoE support: yes, PoE+ (802.3at)

Dimensions: 310 × 260 × 59 mm

Weight: 1445g
