Victron Orion IP67 DC-DC converter 12/24-50A (1500W) non-isolated

Victron Orion DC-DC converter 12/24-50A (1500 W) non-isolated

The professional non-isolated DC/DC converter Victron Orion 12/24-50A (1500 W) offers a number of unique features and easy installation.

Completely sealed: waterproof, shockproof and flameproof

Water, oil and dirt will not damage the Orion DC-DC converter with IP67 protection. The housing is made of cast aluminum and the electronics are encapsulated in resin.

Extra long input and output cables

With 1.8m cables, intermediate cable connections to increase length are often not required, an important feature that increases reliability in areas where IP67 protection is required.

Wide input voltage range

The 15-40V input voltage range ensures stable output during surges or voltage drops caused by other devices connected to the same battery.

BASIC SPECIFICATIONS

Input voltage: DC 10-15V

Output voltage: DC 24 V (+/- 3%)

Maximum continuous output current: 50 A

Efficiency: 96%

Operating temperature range: -40 to +70 °C

Protection level: IP67

Weight: 3 kg

Dimensions: 340 × 127 × 63 mm
