| PERFORMANCE |
| Display Size | 23.8“ |
| View Area | 526.8x296.4 mm |
| Panel | In-Plane Switching |
| Backlight | WLED |
| Aspect Ratio | 16:9 |
| Resolution | 2560x1440 |
| Pixel Pitch | 0.2058x0.2058 mm |
| Dot / Pixel Per Inch | 123 dpi |
| View Angle (H / V) | 178° / 178° |
| Response Time | 4ms GtG (Extreme mode) / 6ms GtG (Typical mode) |
| Color Support | 16.7 Million |
| Refresh Rate | 48Hz - 120Hz |
| Brightness | 300 cd/m2 |
| Contrast Ratio | 1500:1 |
| Color Gamut | 99% sRGB, 99% BT.709 |
| Screen Surface Treatment | Anti-glare |
| Curvature | Flat Panel |
| Camera | Modular Camera Support |
| Microphone | None |
| Speakers | Modular Speaker Support |
| Power Consumption (Typical / Maximum) | 16.5W / 210W |
| Power Adapter | Integrated |
| Touchscreen | None |
| Smart System | None |
| DESIGN |
| Stand | Tilt, Swivel, Pivot, Height Adjust Stand |
| Case Color | Eclipse Black |
| Side Bezel Width | 2 mm |
| Mounting | Supports VESA mount 100 x 100 mm |
| ThinkCentre M Series Support | Tiny Support |
| Pen | None |
| Dimensions (WxDxH) | - Lowest Position | 539.8 x 190.0 x 350.8 mm (21.25 x 7.48 x 13.81 inches)
- Highest Position | 539.8 x 190.0 x 505.8 mm (21.25 x 7.48 x 19.91 inches)
- Head Only | 539.8 x 45.3 x 315.8 mm (21.25 x 1.78 x 12.43 inches)
|
| Packaging Dimensions (WxDxH) | 730 x 123 x 420 mm (28.74 x 4.84 x 16.54 inches) |
| Weight | - Monitor With Stand | 5.6 kg (12.4 lbs)
- Monitor Head Only | 3.6 kg (8.0 lbs)
|
| Packaging Weight | 8.4 kg (18.4 lbs) |
| CONNECTIVITY |
| USB Port | x USB-C® (USB 10Gbps,DP 1.4 Alt Mode HBR3, PD3.1 140W, USB upstream), 1x USB-B (USB 5Gbps, USB upstream), 4x USB-A (USB 5Gbps, 1x BC1.2, USB downstream), 1x USB-C (USB 5Gbps, 15WPD, USB downstream) |
| Video Connector | 1x HDMI® 2.1 TMDS, 1x DP 1.4 (HBR3), 1x DP 1.4 Out, 1x USB-C® (10Gbps, DP 1.4 Alt Mode HBR3) |
| Network Connectivity | 1x RJ45, Ethernet (10M/100M/1000M/2500M) |
| SERVICE |
| Base Warranty | 3-year |
| CERTIFICATIONS |
| Environmental Certification | ENERGY STAR® Certified,TCO 10, TCO Edge 2.1, EU Energy Efficiency Level (Level-D), EPEAT™ Gold |
| Ergonomic Certification | TÜV Rheinland® Eye Comfort 5 Stars, Eyesafe® Display 2.0, TÜV Low Blue Light (Hardware solution) |
| Sync Technology | None |
| Special Features | - HDR10 Compliance
- Factory Calibration: Avg. Delta E<2 at sRGB
- Lenovo® ThinkColour (Lenovo Accessories and Display Manager) Support
Lenovo ThinkColour supports Windows® 10 & 11, Mac OS (functions vary across systems).
Lenovo Accessories and Display Manager is formerly Lenovo Display Control Center. - KVM Switch (with eKVM)
- LDFM (Lenovo® Display Fleet Manager)
- Mirrored Power Button
- Multi-sync
- Natural Low Blue Light
- Smart Power
|
| SOFTWARE |
| Operating System | Support Windows® 10, Windows 11 |
| ACCESSORIES |
| Video Cables | DP cable, USB-C® to USB-C Gen 2 cable, USB-B to USB-A Gen 1 cable |
| MODEL INFORMATION |
| Model | 64B1GAT1EU |
| Machine Type | 64B1 |
| Region | EMEA |
| EAN / UPC / JAN | 0198156544872 / 198156544872 / None |
| Announce Date | 2025-06-12 |
