BASIC SPECIFICATIONS
Physical properties:
Ports: 4× GbE RJ-45, 2× 2.5G SFP, 1× RJ-45 console port (RS-232), 2× DI/DO, 1× alarm output (relay)
Memory: 64Mb, 1024Mb SDRAM
Throughput: 18 Gbps bus, operational 13.3 Mpps (64B)
Transmission support: JumboFrame 10 KB
Design: DIN rail, wall-mounted
Power supply: dual, DC 9–48 V or AC 24 V, total power consumption max. 9.89 W (power supply not included)
Protection: ESD up to 5 kV DC, surge protection up to 6 kV DC
Operating temperature: -40 to +75 °C
Dimensions: 135 × 135 × 60 mm
Weight: 986g
Administration functions:
Management: console via RJ-45, Telnet, Web, SNMP v1/v2c/v3, SSH v2, TLS v1.2
Access Control: ACL based on IP/MAC/Ethertype/protocol/VLAN/DSCP/802.1p, up to 512 rules
L3 routing: max. 8 VLAN interfaces, 32 static routing entries, IPv4/IPv6 SW static routing
ACL filter and bonding: IP ACL, traffic filtering by IP address
MAC ACL, traffic filtering by MAC address
QoS traffic prioritization: traffic classification, strict priority and WRR, 8-level priority for switching (port number, 802.1p priority, 802.1Q VLAN tag, DSCP/ToS field in IP packet)
VLAN support: VLAN according to IEEE 802.1Q standard with tag
IEEE 802.1ad Q-in-Q tunneling
Private VLAN Edge (PVE)
VLAN based on MAC address
Protocol-based VLAN
Voice VLAN
VLAN based on IP Subnet
MVR (Multicast VLAN registration)
GVRP
Up to 4K VLAN groups from 4096 VLAN IDs
Spanning Tree Protocol: STP protocol, IEEE 802.1d Spanning Tree protocol
RSTP protocol, IEEE 802.1w Rapid Spanning Tree protocol
MSTP protocol, IEEE 802.1s Multiple Spanning Tree protocol
BPDU Guard, BPDU Filtering, and Transparent BPDU
Port mirroring: RX, TX, RX+TX, many-to-one
Link aggregation: IEEE 802.3ad LACP, max. 3 trunk groups with max. 6 ports per group
Multicast: IGMP v1/v2/v3, IGMP querier mode support (up to 255 groups), MLD v1/v2, MLD querier mode support (up to 255 groups)
Authentication of connected devices: IEEE 802.1x, RADIUS, TACACS+
LLDP: yes (automatic detection of the type of connected devices)
Wiring diagnostics: yes
