Planet PWR-960-48 industrial DIN rail power supply, 48V DC, 960W

PLANET PWR-960-48

The DIN rail power supply provides sufficient 48V power to industrial PoE devices such as industrial PoE Ethernet switches and industrial PoE wireless access points. Cable connection via terminal block. Active PFC, short circuit, overload, overvoltage and overtemperature protection. Operating temperature range from -30°C to 70°C.

BASIC SPECIFICATIONS

Output circuit:

Output voltage: 48V DC

Output current: 20A

Total output power: 960 W

Protection features: short circuit, overload, overvoltage and overheating

Connection type: screw terminal block

Input circuit:

Input voltage: 200-240V AC, 50/60Hz

Input current: 6 A

Connection type: screw terminal block

Mechanical properties:

Material: metal case, perforated

Dimensions: 150 × 125 × 110 mm

Weight: 2470g

Mounting: DIN rail

Example of use:
